Stainless Steel Precision Casting for auto spare parts

Stainless Steel Precision Casting includes material SS301, SS304, SS304L, SS316, SS316L and SS321. Investment casting method for Precision Casting of Stainless Steel can get a good surface finish and precision dimensions, you only make a slight machining to reach your requriement. The unit weight from 10gs to 100kgs.

 In wax pattern process, we mix stearic acid and paraffin wax in wax pattern making, as you know, it is better than polyethylene,and the wax deformation is small.

 In shell making, we adopt automatic sand-covering production line, which was invented under the guidance of our general manager. The indoor temperature was controlled by air-conditions, keeping the temperature at  24℃±1℃, which can make the Cast Stainless Steel much more stable, the internal tissues much more well-proportioned.

 In shell hardening process, we use aluminium chloride to harden the shell. This can make the shell so hard that it can`t be distorted, at the same time the bug which the casting may have will be decreased.

If there are letters or numbers in it,they will be much clearer.

 In dewaxing process, about 95% of the castings suppliers adopt the original water dewaxing technics, but we using the advanced steam dewaxing technics, which we are very proud of. This can effectively avoid the air-hole and sand-hole,making the casting look much nicer.

 In smelt process, we use middle frequency furnace, avoiding the emergence of the oxide; in molten steel control part, we use Germany-imported direct reading spectrometer machine, assuring its quality before the molten steel out of the furnace.During this process we use ERP production and management software to get the feedback information.

 In shell-knock out process, we have special machines, which can decrease the hitting and knocking, easily made by manual shell knocking out.

 In shot-blasting process, we have crawler-type and hanging shot-blasting machine, with steel shot 0.5-0.8,making the products smooth. Of course, if the customer wants it look much nicer, we also can carry out sand-blast treatment.

 In heat treatment process, we use electric furnace, and adopt double-temperature control in order to heat the products equally. As a result, the products will have great metallurgical structure.

Our tolerance can reach at the grade of 5-7 according to our country`s tolerance standard.

 In machining process, we have 12 CNC machining centers and some other machines, so we can make further machining if the customers need.

 Stainless Steel Cast divides into pump valve accessories casts, food machinery casts, and architectural hardware casts.
